Customized Flanges with Complex Shapes
- Tailor-Made Design: Produced strictly according to customer drawings, models, or samples.
- Wide Size Range: Custom outer diameters, thicknesses, and bore sizes for small to oversized flanges.
- Complex Geometry: Slots, keyways, special grooves and multi-step profiles can be integrated in one piece.
- Precision Machining: CNC turning, milling and drilling ensure tight tolerances and smooth sealing faces.
- Flexible Standards: Compatible with ANSI, ASME, DIN, JIS, EN, GOST or fully non-standard designs.
Technical Specifications
| Item | Specification |
| Product Name | Customized Flanges with Complex Shapes |
| Design Basis | Customer drawings, 3D models, or approved samples |
| Size Range | Custom OD, ID and thickness (e.g. small to large diameters) |
| Pressure Class | According to project requirement (e.g. Class 150–2500, PN6–PN420, etc.) |
| Standards Supported | ANSI / ASME B16.5, B16.47, DIN, EN 1092-1, JIS, GOST, or non-standard |
| Flange Types | Welding neck, slip on, socket weld, threaded, blind, lap joint, special profiles |
| Materials | Carbon steel, stainless steel, alloy steel, duplex / super duplex, special alloys |
| Machining Capability | CNC turning, milling, drilling, threading, groove machining, facing |
| Surface Finish | Custom Ra on sealing faces; rust-preventive coatings on request |
| Dimensional Tolerance | According to customer tolerance class or internal machining standard |
| Testing & Documentation | Material certificates, dimensional reports, NDT (UT/MT/PT) on request |
| Sample Policy | Sample or trial pieces available for design verification |
Customization Options
- Custom OD/ID, thickness and hub geometry based on drawings.
- Choice of flange type: WN, SO, SW, threaded, blind, lap joint, or fully special shapes.
- Personalized bolt-hole pattern: number, diameter, PCD, slotted or tapped holes.
- Tailored sealing faces: RF, FF, RTJ, tongue & groove, male/female, or special grooves.
- Material selection to match pressure, temperature and corrosion requirements.
Applications
- Oil & gas pipelines, manifolds and wellhead equipment
- Chemical and petrochemical plants (reactors, columns, heat exchangers, custom nozzles)
- Power generation (boilers, turbines, condensers, high-pressure piping)
- Refinery and offshore platforms requiring special corrosion-resistant flanges
- Shipbuilding and marine systems for seawater and fuel lines
- Water treatment and desalination plants
- Food, beverage and pharmaceutical equipment with hygiene or cleanability requirements
- General mechanical and pressure vessel projects needing non-standard connections
